MANO311
Industrial Mini ITX Motherboard with Intel® Atom® x6000E Series or Pentium® and Celeron® N & J Series Processors
Features
- Intel® Celeron® processor N3350
- 1 DDR3L SO-DIMM for up to 8GB of memory
- 4GB DDR3L onboard memory (optional)
- 1 PCI Express Mini Card slot and PCIe x1
- 4 USB 3.0 and 2 USB 2.0
- 1 SATA-600, 1 mSATA, and 1 SDXC Mini Card slot
- Supports 6 COM
- Low profile
- Fanless Low Power
- TripleView
- Dual HDMI
- LVDS
- HD Audio
General
CPUIntel® Celeron® processor N3350 (1.1 to 2.4 GHz, 2MB cache, 6W)
ChipsetSoC integrated Chipset Intel® integrated Gfx graphic engine
System Memory1 x 204-pin DDR3L-1867 SO-DIMM, up to 8GB; 4GB onboard memory (optional)
BIOSAMI
Display Interface2 x HDMI
Memory SizeShared memory
USB2 x USB 2.0 (internal); 4 x USB 3.0 (rear I/O)
Serial1 x RS-232/422/485 (rear I/O); 5 x RS-232 (COM 2 with +5/+12V powered)
PS/21 x PS/2 keyboard and mouse combo port
Ethernet2 x 10/100/1000 Mbps Ethernet with Realtek RTL8111F with support for Wake-on-LAN and PXE Boot ROM
AudioHD Codec audio as Mic-in/Line-out with Realtek ALC662/897
Digital I/O16-channel in/out programmable
SATA1 x SATA-600
mSATA1 x mSATA
SDXC1 x SDXC slot
PCI Express1 x PCIe x1
PCI Express Mini Card1 x PCI Express Mini Card slot
SIM Card1 x SIM card slot
Power Input1 x DC Jack; 1 x 4-pin connector
Voltage+12 to 24V DC-in
Adapter12V/5A adapter
BatteryLithium 3V/220 mAH
Watchdog Timer255 levels, 1 to 255 sec.
Dimensions170 x 170 mm
Board Thickness1.6 mm
Operating Temperature0°C to +60°C (+32°F to +140°F)
Humidity10% to 95% relative humidity, non-condensing
TPMN/A
SMBusN/A
