CAPA848
3.5" Embedded Single Board Computer with LGA1151 Socket 9th/8th Gen Intel® Core™ i7/i5/i3 or Celeron® Processor and Intel® Q370
Features
- Intel® Celeron® processor N2807 (1.58 GHz)
- 1 DDR3L-1333 SO-DIMM, up to 8GB
- 4 USB 2.0 ports
- 4 COM ports
- 2 PCI Express Mini Card slots and 1 SIM slot
- Gigabit Ethernet port
- LVDS/VGA/HDMI with dual view supported
- Watchdog Timer (255 levels, 1-255 sec)
- Wake-on-LAN and PXE Boot ROM support
- HD audio codec with MIC-in/Line-in/Line-out
- 1x SATA-300 interface
- 8-CH programmable in/out
- System Management Bus for monitoring/control
- CPU/system temperature and voltage detection
- Lithium battery backup (3V/220mAH)
Computer
ProcessorIntel® Celeron® N2807 1.58 GHz dual core (Bay Trail)
ChipsetSoC Integrated
System Memory1 x 204-pin DDR3L-1333 SO-DIMM, up to 8GB
BIOSAMI
Watchdog Timer255 levels, 1-255 seconds
Display
ChipsetIntel® HD Graphics
Memory SizeShare System Memory
Display Interface1x VGA, 1x LVDS (18/24-bit single/dual channel), 1x HDMI
I/o interfaces
USB4x USB 2.0 ports
Serial4x COM ports (2x RS-232/422/485, 2x RS-232)
Network1x Gigabit Ethernet port with Wake-on-LAN and PXE Boot ROM (Intel I210-AT)
AudioHD Codec with MIC-in/Line-in/Line-out (Realtek ALC888S)
System ManagementSystem Management Bus
Storage
SATA1x SATA-300
Power
Power Input2x 2-pin connector, +12V DC-in only
Power RequirementsIntel® Celeron® N2807 @ 1.58 GHz, 8GB DDR3L, Max. RMS +12V @ 0.64A
BatteryLithium 3V/220mAH
FeaturesAT Auto Power On function supported
Physical
Size146 x 104 mm
Board Thickness1.6 mm
Environmental
Operating Temperature-20℃ to +70℃ (-4°F to +158°F)
Relative Humidity10%-95%, non-condensing
