CAPA842
3.5" Embedded Single Board Computer with LGA1151 Socket 9th/8th Gen Intel® Core™ i7/i5/i3 or Celeron® Processor and Intel® H310
Features
- Intel® Celeron® processor J1900/N2807 (Bay Trail SoC)
- 1 DDR3L-1333 SO-DIMM, up to 8GB
- 4 USB 2.0 ports
- 4 COM ports
- 2 PCI Express Mini Card and 1 SIM slot
- 2 Gigabit Ethernet ports
- LVDS/VGA/HDMI with dual-view supported
Computer
CPUIntel® Celeron® processor J1900 quad core or N2807 dual core onboard (Bay Trail)
System Memory1 x 204-pin DDR3L-1333 SO-DIMM, up to 8GB
ChipsetSoC Integrated
BIOSAMI
Watchdog Timer255 levels, 1 to 255 sec.
Display
ChipsetIntel® HD Graphics
Memory SizeShare System Memory
Display Interface1 x VGA, 1 x LVDS (18/24-bit single/dual channel), 1 x HDMI
Storage
SSD1 x CFast™
Expansion
Expansion Interface1 x Full-size PCI Express Mini Card with mSATA, 1 x Half-size PCI Express Mini Card, 1 x SIM slot
Power
Power Input2 x 2-pin connector, +12V DC-in only, AT Auto Power On function supported
Power RequirementsIntel® Celeron® J1900 @ 2 GHz, 8GB DDR3L Max. RMS. +12V @ 1.41A; Intel® Celeron® N2807 @ 1.58 GHz, 8GB DDR3L Max. RMS. +12V @ 0.64A
BatteryLithium 3V/220mAH
Physical
Size146 x 104 mm
Board Thickness1.6 mm
Environmental
Operating Temperature-20℃ to +70℃ (-4°F to +158°F)
Relative Humidity10% - 95% relative humidity, non-condensing
I/o interfaces
USB4 USB 2.0 ports
COM4 COM ports
Ethernet2 Gigabit Ethernet ports
