CAPA841
3.5" Embedded Single Board Computer with LGA1151 Socket 8th Gen Intel® Core™ i7/i5/i3 or Celeron® Processor and Intel® H310
Features
- Intel® Atom® processor E3845/E3827 (Bay Trail SoC)
- 1 DDR3L-1066/1333 SO-DIMM, up to 8GB
- 4 USB 2.0 ports
- 4 COM ports
- 2 PCI Express Mini Card and 1 SIM slot
- 2 Gigabit Ethernet ports
- LVDS/VGA/HDMI with dual-view supported
- Full-size PCI Express Mini Card with mSATA supported
- Half-size PCI Express Mini Card
- CFast™ SSD support
- Watchdog Timer with 255 levels (1 to 255 sec)
- Lithium 3V/220mAH battery
- Auto Power On function supported
- Operating temperature -40°C to +80°C
Computer
CPUIntel® Atom® processor E3845 quad-core or E3827 dual-core onboard (Bay Trail)
ChipsetSoC Integrated
BIOSAMI
System Memory1x 204-pin DDR3L-1066/1333 SO-DIMM, up to 8GB
Watchdog Timer255 levels, 1 to 255 sec
Storage
SSD1x CFast™
I/o interfaces
USB 2.0 ports4
COM ports4
Gigabit Ethernet ports2
Display
Display ChipsetIntel® HD Graphics
Memory SizeShare System Memory
Display Interface1x VGA, 1x LVDS (18/24-bit single/dual channel), 1x HDMI
Power
Power Input2x 2-pin connector, +12VDC-in only
Power Requirements (E3845 @ 1.91GHz, 8GB DDR3L)+12V @ 1.22A Max. RMS
Power Requirements (E3827 @ 1.75GHz, 8GB DDR3L)+12V @ 0.96A Max. RMS
BatteryLithium 3V/220mAH
Physical
Size146 x 104mm
Board Thickness1.6mm
Environmental
Operating Temperature-40°C to +80°C (-40°F to +176°F)
Relative Humidity10%-95% non-condensing
