CAPA312
3.5" Embedded Single Board Computer with Intel® Atom® x6000E Series or Pentium® and Celeron® N & J Series Processors
Features
- Intel® Pentium® processor N4200/Celeron® processor N3350
- 1 DDR3L SO-DIMM, up to 8GB
- 2 USB 2.0 and 4 USB 3.0
- 2 PCI Express Mini Card slots
- HDMI/LVDS display support
- Dual GbE LAN with Wake-on-LAN and PXE Boot ROM
- 1x SATA-600 interface
- HD Audio codec (Realtek ALC888S) with Mic-in/Line-in/Line-out
- 2x RS-232/422/485 and 2x RS-232 serial ports
- 8 channels programmable Digital I/O
- TPM 2.0 compliant security module
- Hardware monitoring (CPU/system temperature, voltage, fan speed)
- SMBus compatible with I2C
- Watchdog Timer (65536 levels, 1~65535 sec)
- Lithium battery backup (3V/220mAH)
- AT Auto Power On function
Computer
CPUIntel® Pentium® processor N4200 (1.1 to 2.5 GHz, 2MB Cache, 6W) or Intel® Celeron® processor N3350 (1.1 to 2.4 GHz, 2MB Cache, 6W)
ChipsetSoC Integrated
System Memory1x204-pin DDR3L-1867 SO-DIMM, up to 8GB
BIOSAMI
TPMST ST33HTPH2X32AHD8 with TPM 2.0 compliant
Display
Display OutputHDMI/LVDS
I/o interfaces
Ethernet2 ports 10/100/1000 Mbps with Wake-on-LAN, PXE Boot ROM with Intel® I210-AT
Serial Ports2x RS-232/422/485, 2x RS-232
USB2x USB 2.0, 4x USB 3.0
AudioHD Codec audio (Mic-in/Line-in/Line-out) with Realtek ALC888S
Digital I/O8 channels in/out programmable
SMBusYes, compatible with I2C
Storage
SATA1x SATA-600
Expansion
PCI Express Mini Card1x Full-size with mSATA support, 1x Full-size
SIM Slot1x
Power
Power Input2x2-pin connector +12V DC-in only
Power Requirements (N4200)+12V @ 1.5A (8GB DDR3L Max. RMS)
Power Requirements (N3350)+12V @ 1.2A (8GB DDR3L Max. RMS)
BatteryLithium 3V/220mAH
Watchdog Timer65536 levels, 1~65535 sec
Physical
Size146x104mm
Board Thickness1.6mm
Optional Chassis Dimensions (with wall mount ear)207.5mm (8.17") W x 140mm (5.51") D x 35mm (1.37") H
Environmental
TemperatureStandard -20°C to +60°C (-4°F to +140°F), Optional -20°C to +70°C (-4°F to +158°F)
Optional Chassis Operating Temperature-10°C to +50°C (+14°F to +122°F)
Relative Humidity10% to 95% non-condensing
Certifications
Hardware MonitoringCPU/system temperature, voltage and fan speed detection
Computer
CPUIntel® Pentium® processor N4200 (1.1 to 2.5 GHz, 2MB Cache, 6W) or Intel® Celeron® processor N3350 (1.1 to 2.4 GHz, 2MB Cache, 6W)
ChipsetSoC Integrated
System Memory1x204-pin DDR3L-1867 SO-DIMM, up to 8GB
BIOSAMI
TPMST ST33HTPH2X32AHD8 with TPM 2.0 compliant
Display
Display OutputHDMI/LVDS
I/o interfaces
Ethernet2 ports 10/100/1000 Mbps with Wake-on-LAN, PXE Boot ROM with Intel® I210-AT
Serial Ports2x RS-232/422/485, 2x RS-232
USB2x USB 2.0, 4x USB 3.0
AudioHD Codec audio (Mic-in/Line-in/Line-out) with Realtek ALC888S
Digital I/O8 channels in/out programmable
SMBusYes, compatible with I2C
Storage
SATA1x SATA-600
Expansion
PCI Express Mini Card1x Full-size with mSATA support, 1x Full-size
SIM Slot1x
Power
Power Input2x2-pin connector +12V DC-in only
Power Requirements (N4200)+12V @ 1.5A (8GB DDR3L Max. RMS)
Power Requirements (N3350)+12V @ 1.2A (8GB DDR3L Max. RMS)
BatteryLithium 3V/220mAH
Watchdog Timer65536 levels, 1~65535 sec
Physical
Size146x104mm
Board Thickness1.6mm
Optional Chassis Dimensions (with wall mount ear)207.5mm (8.17") W x 140mm (5.51") D x 35mm (1.37") H
Environmental
TemperatureStandard -20°C to +60°C (-4°F to +140°F), Optional -20°C to +70°C (-4°F to +158°F)
Optional Chassis Operating Temperature-10°C to +50°C (+14°F to +122°F)
Relative Humidity10% to 95% non-condensing
Certifications
Hardware MonitoringCPU/system temperature, voltage and fan speed detection
