Q7M311
Qseven Qseven Computer-on-Module with Intel® Pentium® Processor N4200 & Celeron® Processor N3350
Features
- Intel® Pentium® processor N4200 & Celeron® processor N3350 (Apollo Lake)
- Onboard 4GB DDR3L memory
- 4 lanes of PCI Express slot
- 2 SATA-600
- 3 USB 3.0 and 4 USB 2.0
- 1 port 10/100/1000 Mbps Ethernet with Wake-on-LAN and PXE Boot ROM
- HD link interface to baseboard for Codec
- 8x GPIO Digital I/O
- SMBus support
- SDIO support
- Smart Battery support
- Hardware Monitoring
- Intel® Gen 9 Graphics Engine (DX11.1, OCL1.2, OGL 4.2)
- 1 x DDI (DP, HDMI, DVI) and 1 x LVDS display interface
Processor
CPUIntel® Pentium® N4200 or Celeron® N3350 (Apollo Lake)
Memory
Onboard DDR3L4GB
Storage
SATA2x SATA-600
Expansion
PCI Express4 lanes
LPC1x (optional)
SPI1x
Serial1x TX/RX
I2C1x
SDIO1x
I/o interfaces
USB3x USB 3.0, 4x USB 2.0
Ethernet1x 10/100/1000 Mbps with Wake-on-LAN and PXE Boot ROM (Intel® I210)
GPIO8x Digital I/O
AudioHD link interface to baseboard
Display
GraphicsIntel® Gen 9 Graphics Engine
Graphics SupportDX11.1, OCL1.2, OGL 4.2
Display Interface1x DDI (DP, HDMI, DVI), 1x LVDS 18/24-bit dual channel (eDP optional)
Management
Hardware MonitoringYes
SMBusYes
Smart BatteryYes
TPMN/A
